6W UL
18W-GS
18W-UK
6W GS
18W-AU
6W BS
18W-UL
6W SAA
面）.jpg)
面）.jpg)
| Input | Rated Input Voltage | 100VAC-240VAC | Rated Input Frequency | 50/60Hz | |
| Input Voltage Range | 90VAC-264VAC | Inrush Current | 30A Max | ||
| Input Current | 0.5A Max | Leakage Current | 0.7mA Max | ||
| Efficiency | CEC DOE ERP GEMS （LEVEL VI） | ||||
| Output | utput Voltage | DC 5.0-24V | |||
| Voltage Regulation | ±5% constant Voltage Mode | ||||
| Output Current Regulation | ±5% constant Current Mode | ||||
| Output Current | 0.01A-3.0A | ||||
| Ripple and Noise | 200mVp-p max @20MHz Bandwidth 10uF Ele.Cap.+0.1uF Cer.Cap. | ||||
| Maximal Power | 15W max | ||||
| Turn-On Delay Time | Less than 3S Typical At Full Load | ||||
| Hold-up Time | 10ms Typical At Full Load | ||||
| Protection | Over-current Protection; short-circuit Protection; ver-voltage Protection | ||||
| DC Cable | UL2468&UL2464& UL1185 | ||||
| The certificate | UL/ GS/CE/CB/SAA/BSMI/KC/PSE/CCC/FCC/EMC/LVD/C-TICK/RCM | ||||
| standard | EMC | CISPR32/EN55032 CISPR24/EN55024 EN 61000 FCC Part 15 | |||
| Safety | IEC/EN/ AS/NZS 62368/60950&UL62368/60950 | ||||
| Environmental | Operation Temperature | 0℃ to 40℃ ambient | |||
| Storage Temperature | .-10℃ to 75℃ | ||||
| High-Reliability: MTBF > 20000 Hours under 25℃ | |||||
| Weight | 80g | ||||
